Certification :
RoHS
Price :
Negotiable
Brand Name :
YESWITCH
Model Number :
PBL Series
Place of Origin :
China
Payment Terms :
T/T
Model NO. :
PBL Series
Wiring :
Single Live Line
Principle :
Capacitive
Application :
Home Appliance, Electronics, Lighting, Industrial, Apartment/Villa, Hotel, Commercial, Home
Type :
Normal Open
Number of Switch :
Single Control Switch
Structure :
Power Built-in Type
Usage :
Control Button, Start Button, Limit Button, Reset Button, Check Button, Playback Switch, Disconnector, Change-over Switch, Control Switch
Kind :
Single-pole on-off Switch
Contact Type :
Solde
Detection Method :
Retro-reflective Mode
Brand :
Yeswitch
Pole-Position :
Momentary Type, Spst with LED
Contact Rating :
30V DC, 0.1A
Contact Resistance :
50mΩ Max. 1.5V DC; 100mA by Method of Voltag
Insulation Resistance :
100mΩ Min. 500V DC.
Dielectric Strength :
500V AC for 1 Minute.
Operating Force :
250± 100GF.
Operating Life :
50, 000 Cycles.
Operating Temperature Range :
-40°c ~ 85°c.
Total Travel :
1.2± 0.3mm.
Cap :
PC.
Case & Housing :
Nylon 6/6.
Terminals :
Copper Alloy with Gold Plated.
Transport Package :
Carton
Specification :
8mm
Trademark :
YESWITCH
Origin :
China
HS Code :
8536500000
Supply Ability :
50, 000/Month
Package Size :
9.00cm * 8.00cm * 5.00cm
Package Gross Weight :
0.010kg
Customization :
Available
Protection :
Durable, Explosion-Proof, Waterproof, Dust-Proof, Insulation
Feature :
Flat Round Cap
